Vaccine transport cooler box

Medicine Cooler Box For Long Distance Vaccine transport cooler box

260L Large Capacity Medical Cold Chain Box Transport Vaccine Cooler BoxThis is a Bio Medical Blood Transportation cooler bag, outer material is PE plastic or Oxford bag, and internal material is PU or VPU Splicing box,The combination of them can keep your contents cold for more than 72 h.PU or

External Dimension：630x630x630mm
Internal Dimension： 500x500x500mm
Capacity: 125L
Weight: 25KG

Description
Message

85L Large Capacity Medical Cold Chain Box Transport Vaccine Cooler Box

This is a Bio Medical Blood Transportation cooler bag, outer material is PE plastic or Oxford bag, and internal material is PU or VPU Splicing box, The combination of them can keep your contents cold for more than 72 h.PU or VPU provide energy efficiency and space benefits for home appliances, temperature-controlled packaging, refrigerated transportation systems and any other applications that require low energy loss from heat transfer.

Item

Specification

With cold plate

Material

BWX-85L

External size: 630x630x630mm

Internal size: 500x500x500mm

Capacity :125L

Inside size : 440x440x440mm

Avaliable Capacity :85L

Outside : Oxford bag or PE box

Inside : PU or VPU Recommend According to demands

Instructions for use:

The First Step : Freeze PCM in a at 0 degrees or less freezer for at least 10 hours to ensure complete freezing. ( At the same time, if you need better cooling conditions, please also pre-cool the insulation cooler Box)
The Second Step : Take out the Frozen PCM and place it around the Insulation box and release cool about half an hour

The Third Step : Put in medicine,vaccine ,blood that needs to be cold storage, the last , place the top PCM and Cover the lid tightly.

Box Structure Description:

- WE ARE DIFFERENT !

After several times of research and testing, Self-assembling pu insulation box have applied for our company's Patent. PCM cold palte can meet for different temperature request.

-Precise design allows for seamless self-assembly

-Save transportation costs

Why do cold chain transport box, transport trucks use white?

Studies show that the same exposure, the surface temperature difference, up to 10℃ difference. High surface temperature differences reduce holding time,
And thermal conductivity of thermal insulation materials with the rise of surface temperature, accelerate the decay of thermal insulation time, and accelerate the aging of materials.

PU-VIP Insulation Cooler Box application:

Medical cooler Boxes, are used to transport blood products, organs and pharmaceuticals that require stable temperatures to maintain their life saving and life giving properties.

Ideal For Transporting Medicines such as :

-- Selected fresh food, drink and dairy products

-- Vaccines

-- Insulin

-- Breeding Programs

-- Biopharmaceutical, Life Science and other Medical Products

-- IVD products and biological specimens
